DVI-I combines DVI-A and DVI-D connections to include both analog and digital components. DVI-D carries only digital video (for example, HDMI) with no analog component. The connector type is not a definitive indicator of the maximum resolution.ĭVI-A carries only analog (for example, VGA) with no digital component.
Note: The maximum resolution of your video source and video destination are ultimately determined by the technical specifications of the devices. The maximum resolutions are Single Link (1920 x 1080 60Hz) and Dual Link (2560 x 1600 60Hz).
Single and Dual link DVI indicate the maximum resolution capabilities of the video source or video destination. DVI comes in the following five different connector types: The connector types are identified by the number of pins on the DVI connector. DVI cables and ports are created using different connector types to identify what application they are intended to be used in. Note: In order for your setup to work properly, the video source, adapter, and destination all need to support the resolution that you are using.ĭigital Visual Interface (DVI) is a video display interface that can contain different types of signaling, based on the application. Test to make sure that the video source and video destination work together at the resolution that you want to use. Remove the video adapter from your setup and test to make sure that the video source and video destination work together without the video adapter. When you test the video source and video destination, it is recommended that you do the following: When you test your cables, it is recommended that you do the following: Ideally, you should test a component that you know works in another setup. Use a different cable, video adapter, video source, and video destination in your setup to see if the problem persists. Use the cable, video adapter, video source, and video destination in another setup to see if the problem is with the components or the setup. To test your setup components, try the following:
Video destination (such as a monitor or projector) Video source (such as a DVD player or computer) You can test to make sure that the following components are working correctly and are not the source of the issue: When you troubleshoot issues with a video adapter, there are some quick tests that you can complete to rule out potential problems.
#THUNDERBOLT MINI DISPLAYPORT DP TO VGA HDMI DVI ADAPTER FOR MACBOOK PRO AIR MAC DRIVER DRIVERS#
EASY TO USE: With no software or drivers required, the Mini DP to DVI converter works with any OS including Windows, Ubuntu and macOS Compatible with MiniDP devices like TB1/TB2 MacBooks with Mini DisplayPortĭP++ (DisplayPort++) port required from video card or video source for DVI and HDMI® signal pass-through.SCREW LOCKING DVI: Mini DisplayPort to DVI display adapter supports DVI screw locking cable to prevent cable from coming loose or accidental disconnection from DVI displays/projectors | Tested with DVI cables up to 25ft | mDP male to DVI female connector.INCREASE PRODUCITIVTY: Connect a DVI monitor or projector, or add a second display to your workstation using the mDP to DVI adapter dongle | Compact design makes it ideal for travel | 5" (13cm) attached cable.HOST COMPATIBILITY: Passive video converter supports mDP++ source including Thunderbolt 1 & 2 MacBooks, MacBook Air & Mac Mini, Microsoft Surface Pro 1-6, desktops (AMD FirePro/NVidia Quadro), laptops, mini itx computers, Intel NUC & docks.MINI DISPLAYPORT TO DVI ADAPTER: mDP 1.2 (HBR2) to DVI-I (digital only DVI-D) single-link adapter connects a DVI display/projector supporting 1920x1200/1080p 60Hz video EDID/DDC pass-through ensure compatibility between source & display.
